Metal Shear Blade & Guillotine Shear Blade
Home / Shearing Blade /

Metal Shear Blade & Guillotine Shear Blade

Metal Shear Blade & Guillotine Shear Blade

Application

Our metal shearing blades and machine knives are mainly used in gate shears, flying shears and cut-to-length shears. It can cut stainless steel plates, silicon steel sheets, galvanized plates, cold-rolled and hot-rolled plates, copper plates, etc. of various thicknesses. Because cross-cutting machines cut frequently, the quality of their blades is important. Seton blades have excellent surface quality and high wear resistance, which can reduce downtime caused by blade replacement due to sharpening and enable continuous production, thereby improving production efficiency. Of course, gap adjustment is also very important when shearing materials of different thicknesses.



Material Introduction

Metal shearing machine blades mainly use 6CrW2si, Cr12MoV, SKD-11, H13, H13K, D2, W6Mo5Cr4V2, tungsten carbide and other materials. Since customers cut a wide range of material thicknesses and are unwilling to change blades frequently, SHINITE developed a new material HMB,HMK, which has high flexibility and good wear resistance and can cut 5-16mm and 10- At the same time 20mm steel plate.



Feature

  • High wear resistance. Before the blade becomes dull, the capacity to shear conventional materials in a single pass generally reaches 9,000-15,000 tons.
  • High accuracy. After heat treatment, it is ensured that the hole spacing tolerance meets the requirements for assembly with various machines.



custom made

  1. Our metal shear blades and guillotine shear blades are available in custom lengths up to 5000mm. According to the cutting material, the hardness can be customized to HRC 53-70, and it can cut metal materials from 0.1mm to 32mm.
  2. Using high-quality raw materials and special heat treatment process, after multiple temperings, it can be cut for a long time without breaking the blade.
  3. The quality of each blade is 100% inspected, and only qualified blades will be delivered to customers.
